Aoraki 9,000 BTU Ceiling Cassette Mini Split Air Conditioner, 24 SEER2 - 230V

Name: Aoraki 9,000 BTU Ceiling Cassette Mini Split Air Conditioner, 24 SEER2 - 230V
Brand: TOSOT Direct
SKU: TST-SU-A9KC
Price: 1499.99 USD
Availability: InStock

$1,499.99

$1,499.99 ~~$1,499.99~~

Now $1,099.99 USD

$1,499.99

$1,499.99 ~~$1,499.99~~

Pre Order

EARLY BIRD OFFER: $400 OFF

SKU: TST-SU-A9KC

Model: Aoraki

🔥 Early Bird Pre-Order | Expected to Ship Mid-October

Key Features

Up to 24 SEER2 & 9.2 HSPF2 with R32 Refrigerant
ENERGY STAR Certified with tax rebate eligibility
8-way airflow with 7-speed fan control for customized comfort
Built-in condensate pump with 47.2" lift
Operates in Extreme Temperatures from -40°F to 140°F
Quiet operation as low as 27 dB
Built-in Refrigerant Leakage Sensor for added safety

BTU Model

Product variants

View full details

Features
Tech Specs
Reviews
Manuals
FAQ

🔥 Early Bird Pre-Order | Expected to Ship Mid-October

Key Features

Up to 24 SEER2 & 9.2 HSPF2 with R32 Refrigerant
ENERGY STAR Certified with tax rebate eligibility
8-way airflow with 7-speed fan control for customized comfort
Built-in condensate pump with 47.2" lift
Operates in Extreme Temperatures from -40°F to 140°F
Quiet operation as low as 27 dB
Built-in Refrigerant Leakage Sensor for added safety

PERFORMANCE
Cooling Capacity	9,100 Btu/h	Heating Capacity	10,500 Btu/h
EER	15.0 Btu/h/W	COP	13.1 Btu/h/W
SEER2	24	HSPF2	9.2
Voltage	208/230V, 60Hz, 1Ph	Dehumidification	1.69 Pts/hr
Rated Power of Cooling	606 W	Rated Power of Heating	799 W
Rated Current of Cooling	3.1 A	Rated Current of Heating	4.0 A
Rated Power Max.	1,330 W	Rated Current	6.1 A
Min. Current (MCA)	10 A	Max. Over Current Protection	15 A
Temperature Setting Range	61–86°F	Lowest Noise Level	27 dB(A)
Energy Star & UL Certified	Yes	Built-in Pump	Yes

DIMENSIONS & WEIGHTS
Indoor Unit
Approximate Shipping Weight	48.5 lbs	Approximate Net Weight	37.5 lbs
Shipping Dimensions (W × H × D)	27 23/64 × 25 38/64 × 11 2/64 in	Unit Dimensions (W × H × D)	22 28/64 × 22 28/64 × 10 28/64 in
Outdoor Unit
Approximate Shipping Weight	76.1 lbs	Approximate Net Weight	70.6 lbs
Shipping Dimensions (W × H × D)	34 7/32 × 15 35/64 × 23 25/64 in	Unit Dimensions (W × H × D)	31 37/64 × 21 27/32 × 13 25/32 in
Line Set
Copper Line Set Length	16 ft	Max. Line Set Length	65 ft
Copper Line Set Size	1/4" & 3/8"	Max. Height Difference	40 ft

COVERAGE AREA GUIDE
Application / Ceiling Height	9,000 BTU	12,000 BTU	18,000 BTU	24,000 BTU
Residential
Ceiling Height < 7.9 ft. (2.4 m)	412–450 sq. ft.	688–750 sq. ft.	1,100–1,200 sq. ft.	1,375–1,500 sq. ft.
Ceiling Height 7.9–9.8 ft. (2.4–3.0 m)	375–450 sq. ft.	625–750 sq. ft.	1,000–1,200 sq. ft.	1,250–1,500 sq. ft
Ceiling Height 9.8–11.8 ft. (3.0–3.6 m)	319–375 sq. ft.	531–625 sq. ft.	850–1,000 sq. ft.	1,062–1,250 sq. ft.
Ceiling Height 11.8–13.8 ft. (3.6–4.2 m)	281–319 sq. ft.	469–531 sq. ft.	750–850 sq. ft.	938–1,062 sq. ft
Commercial / Office / Retail
Ceiling Height 7.9–9.8 ft. (2.4–3.0 m)	319–356 sq. ft	531–594 sq. ft.	850–950 sq. ft.	1,062–1,188 sq. ft.
Ceiling Height 9.8–11.8 ft. (3.0–3.6 m)	292–330 sq. ft	488–550 sq. ft.	780–880 sq. ft.	975–1,100 sq. ft.
Ceiling Height 11.8–13.8 ft. (3.6–4.2 m)	244–292 sq. ft.	406–488 sq. ft.	650–780 sq. ft.	812–975 sq. ft
Ceiling Height >13.8 ft. (>4.2 m)	206–244 sq. ft.	344–406 sq. ft.	550–650 sq. ft.	688–812 sq. ft.

*Coverage recommendations are estimates based on typical room conditions. Actual cooling and heating capacity requirements may vary depending on insulation, climate, windows, occupancy, heat-generating equipment, and other site conditions.

Q: What is the required clearance height for installing a ceiling cassette AC?

A: 9,000 ~18,000 BTU: Requires a ceiling clearance of 11 ½ inches. This provides an extra 1.1 inches beyond the minimum requirement, giving you plenty of space for piping, drainage, and panel installation.

24,000 BTU: Requires a ceiling clearance of 10 ½ inches, which also includes an extra 1.1 inches of buffer space for seamless installation.

Q: How do I clean and maintain this mini split system?

A: We recommend routine maintenance once a season. Simply remove and clean the air filters, inspect the evaporator and condenser coils, and clear any debris around the outdoor unit for optimal performance.

Q: Can I install this AC unit myself, or do I need a professional?

A: This is not a DIY system. We strongly recommend having it installed by a licensed HVAC professional to ensure proper setup, optimal efficiency, and safety.

Q: What are the energy efficiency ratings and coverage areas for each model?

A: 9K BTU: 24 SEER2 / 9.2 HSPF2 | Covers up to 194 sq. ft.

12K BTU: 23 SEER2 / 9.0 HSPF2 | Covers up to 258 sq. ft.

18K BTU: 21 SEER2 / 9.0 HSPF2 | Covers up to 366 sq. ft.

24K BTU: 22.5 SEER2 / 9.0 HSPF2 | Covers up to 452 sq. ft.

Q: What is the warranty on your products?

A: Every unit is backed by our manufacturer's warranty, coming with an 8-year compressor warranty and a 5-year parts warranty.

Q: Does the package include all the accessories needed for installation?

A: Yes, it includes a 16.4 ft line set and most essential installation accessories. Please note: power cables/electrical wiring are not included and must be sourced separately.

Q: How does the drainage system work on your ceiling cassette?

A: Condensate water collects in the built-in drain pan and routes outside via the drain pipe. To ensure hassle-free operation, this unit features a built-in condensate drain pump, which helps lift and evacuate water efficiently even when natural gravity drainage isn't sufficient.

8-Way Air, 7-Speed Control

Four sides equipped with wide-angle adjustable air deflectors for extended airflow range.

Strategic corner openings allow air overflow; achieves shower-style air distribution with eight-way air outlets; provides up to 330 CFM airflow for large spaces

Powerful Cooling & Heating

9,000 BTU ceiling cassette mini-split air conditioner delivers up to 330 CFM airflow; 7 fan speeds, including Turbo mode, ensure rapid temperature adjustment; operates in conditions from -40°F to 140°F

Remote Control

Includes remote for convenient operation; switch between cooling, heating, dehumidifying, and 7-speed fan modes for year-round comfort; sleep mode and timer for personalized settings

Why Trust TOSOT?

5-Year Standard Warranty

Cover both the compressor and parts.If you need installation services or product assistance, please contact support@tosotdirect.com

Manufactured by Gree

With Gree's over 30 years of manufacturing experience in the AC industry, we always strive to provide the highest quality product to all our customers.
